Size
Tipping container: 1025 – 1155 x 600 – 860 x 325 mm
Material
Rubber
Aluminium
Plastic
Steel
Colour
Blue
Fuel consumption [g/kWh]
395
Max forward speed [km/h]
5
Max reverse speed [km/h]
2.5
Transmission mode
3 gears forward + 1 reverse gear
Engine type
Single cylinder, 4-stroke, air-cooled (OHV)
Drive belt type
Direct V-belt drive
Track width
180 mm
Engine power
4.1 kW
Sound power
99.5 dB
Limited grade ability
15 °
Load capacity – capacity max.
500 kg
Oil tank capacity
0.55 l
Fuel tank capacity
3.6 l
Tipping container tilt angle [°]
48
Dimensions (LxWxH)
174 x 73 x 109 cm
Weight
238 kg
Shipping dimensions (LxWxH)
143 x 77 x 89 cm
Shipping weight
266 kg
